Key Features
- PN=2kW: Power rating identified as PN=2kW.
- UDC=600V: DC-link voltage identified as UDC=600V.
- M0=28Nm (100K): Starting torque designation identified as M0=28Nm (100K).
- NN=3000rpm: Rated speed designation identified as NN=3000rpm.
- Resolver feedback: Equipped with a resolver 2-pole / Resolver R14DQ feedback system with drive cliq-interface.
- IP65 protection: Degree of protection is IP65.
Technical Summary
| PN | 2kW |
|---|---|
| UDC | 600V |
| M0 | 28Nm (100K) |
| NN | 3000rpm |
| Rated speed (100 K) | 3,000 rpm |
| Static torque (100 K) | 28.00 Nm |
| Rated current | 5.7 A |
| Number of poles | 8 |
| Degree of protection | IP65 |
| Encoder system | Resolver R14DQ: resolver 14 bits (resolution 16384, internal 2-pole) |
| Holding brake | without holding brake |
| Cooling | Natural cooling |
Applications
- Motion control integration with SINAMICS S120: Motor for motion control use with SINAMICS S120.
Frequently Asked Questions
What is the exact Siemens model of this motor?
The exact model is 1FK7086-4CF71-1PG1.
What are the key power and speed ratings for 1FK7086-4CF71-1PG1?
The motor is identified with PN=2kW and NN=3000rpm. The rated speed (100 K) is 3,000 rpm.
Which feedback and connection details are specified for 1FK7086-4CF71-1PG1?
It uses a resolver 2-pole / Resolver R14DQ feedback system and electrical connectors for signals and power rotatable.
What mechanical configuration is specified for 1FK7086-4CF71-1PG1?
It has IM B5 (IM V1, IM V3) mounting, a plain shaft, and no holding brake.
