Key Features
- Power and speed: PN=1.2kW; NN=3000rpm.
- Torque and electrical data: M0=4.5Nm (100K); UDC=600V.
- Feedback and interface: Absolute encoder SINGLETURN 24 BIT with DRIVE CLIQ interface (ENCODER AS24DQI).
- Mechanical configuration: Naturally cooled, FRAME SIZE IMB 5 (IM V1, IM V3), plain shaft, tolerance N, without holding brake.
- Protection and connection details: Degree of protection IP64; power connector rotatable; connector size M23.
Technical Summary
| Product type | SIMOTICS S Synchronous motor |
|---|---|
| PN | 1.2kW |
| UDC | 600V |
| M0 | 4.5Nm (100K) |
| NN | 3000rpm |
| Encoder system | Encoder AS24DQI: absolute encoder single-turn 24 bits |
| Degree of protection | IP64 |
| Cooling | Natural cooling |
| Design acc. to Code I | IM B5 (IM V1, IM V3) |
| Connector size | M23 |
| Shaft end | Plain shaft |
| Holding brake | without holding brake |
Frequently Asked Questions
What is Siemens 1FK7044-4CF71-1BG0?
It is a SIMOTICS S synchronous motor.
What are the key ratings of 1FK7044-4CF71-1BG0?
PN=1.2kW, NN=3000rpm, and M0=4.5Nm (100K).
What encoder does 1FK7044-4CF71-1BG0 use?
It uses Encoder AS24DQI, an absolute encoder single-turn 24 bits with DRIVE CLIQ interface.
What mechanical configuration should be confirmed for 1FK7044-4CF71-1BG0?
It has natural cooling, FRAME SIZE IMB 5 (IM V1, IM V3), a plain shaft, and no holding brake.
