Key Features
- ET 200S digital output module: SIMATIC DP spare part with 5 electronic modules for ET 200S.
- 2 DO Standard outputs: Provides 2 digital outputs.
- Output rating: 24 V DC/2 A.
- Compact width: 15 mm width.
- Packing unit: 5 units per packing unit.
Technical Summary
| Product function | SIMATIC DP, 5 electronic modules for ET 200S |
|---|---|
| Digital outputs | 2 |
| Digital output type | Source output (PNP, current-sourcing) |
| Load voltage L+ | 24 V; From power module |
| Output current for signal "1" rated value | 2 A |
| Switching capacity on lamp load, max. | 10 W |
| Address space per module, max. | 1 byte |
| Power loss, typ. | 1.4 W |
Applications
- Digital output switching: Switching 24 V DC loads through 2 digital outputs.
- Redundant load control: Parallel switching of two outputs for redundant control of a load.
Frequently Asked Questions
What is Siemens 6ES7132-4BB31-0AA0?
It is a SIMATIC DP spare part with 5 electronic modules for ET 200S and 2 DO Standard outputs.
What are the output ratings of 6ES7132-4BB31-0AA0?
The module has 24 V DC load voltage and a rated output current of 2 A for signal "1".
How many digital outputs does 6ES7132-4BB31-0AA0 have?
It has 2 digital outputs.
What are the dimensions of 6ES7132-4BB31-0AA0?
The module measures 15 mm wide, 81 mm high, and 52 mm deep.
What is the lifecycle status of 6ES7132-4BB31-0AA0?
Product cancellation.
